MOTU 28×32 TB4/USB4 interface with mix, FX, AVB

The MOTU 848 turns any Mac, PC or iOS device into a complete 28×32 recording system over a single 40 Gbps Thunderbolt 4 / USB4 connection. With 60 simultaneous channels of I/O and ESS Sabre32 Ultra DAC technology delivering 125 dB of dynamic range at sample rates up to 24-bit/192kHz, it captures every source with vanishing distortion (-114 dB THD+N) and round-trip latency as low as 1.8 ms.

Four combo XLR/TRS inputs supply transparent mic preamps with up to +74 dB of gain, a switchable -20 dB pad, 48V phantom power and remote control, doubling as hi-Z guitar DIs with dedicated send/return inserts on channels 3-4. Eight additional line inputs and twelve DC-coupled TRS outputs handle outboard gear, synth CV and immersive monitoring up to 7.1.4 Dolby Atmos, while two banks of optical I/O and word clock keep your digital rig in sync.

A 32-bit floating-point DSP engine drives a 64-channel, 32-bus mixer with reverb, EQ, gate and compression, all controllable from the CueMix Pro app over USB, Wi-Fi or the network. Dual Gigabit AVB ports let you daisy-chain up to eight 848 or 16A units for hundreds of networked channels, and a 3.9-inch RGB TFT display, loopback recording and A/B/C monitoring with talkback complete the rugged 1U package.

Visit Support Site

SKU MOT-848

MOTU 28×32 TB4/USB4 interface with mix, FX, AVB

RRP $2999.00

28×32 Thunderbolt 4 / USB4 interface, 60 simultaneous channels
4x combo XLR/TRS mic/line/hi-Z preamps, +74 dB gain
ESS Sabre32 Ultra DAC, 125 dB dynamic range, up to 192 kHz
12x DC-coupled TRS line outs for monitoring & modular CV

Vendor Item No. 9301
UPC/EAN 839128006294

MOTU 28×32 TB4/USB4 interface with mix, FX, AVB
