MOTU 28×32 USB3 interface with mix, FX for Mac/Win

The MOTU 828 turns any Mac, PC or iOS device into a 28×32 recording system over a single 5 Gbps USB-C connection. Built on ESS Sabre32 Ultra DAC technology, it delivers 60 simultaneous channels with 125 dB of dynamic range at up to 24-bit/192kHz, -114 dB THD+N and round-trip latency as low as 2 ms — the fifth generation of MOTU's long-running 828.

Two combo XLR/TRS inputs provide transparent mic preamps with +74 dB of gain, a -20 dB pad, 48V phantom power, phase invert and dedicated send/return inserts, doubling as hi-Z guitar DIs. Eight line inputs, eight DC-coupled TRS outputs, dedicated XLR main outs and two pre-converter sends cover monitoring, outboard gear and synth CV, while two banks of optical I/O, RCA S/PDIF, word clock, MIDI and a footswitch input round out the connectivity.

An onboard 24-channel mixer with 32-bit DSP adds reverb, 4-band EQ and compression for near-zero-latency monitoring, controllable from the CueMix 5 app over USB or Wi-Fi — and the 828 works standalone as a mixer with no computer attached. A 3.9-inch RGB TFT display, two headphone outputs, loopback recording and A/B/C monitoring with talkback complete the rugged 1U chassis.

Visit Support Site

SKU MOT-828

MOTU 28×32 USB3 interface with mix, FX for Mac/Win

RRP $2099.00

28×32 USB3 (USB-C, 5 Gbps) interface, 60 simultaneous channels
2x combo XLR/TRS mic/line/hi-Z preamps, +74 dB gain
ESS Sabre32 Ultra DAC, 125 dB dynamic range, up to 192 kHz
8x line inputs, 8x DC-coupled TRS outs + dedicated XLR main outs

Vendor Item No. 9390
UPC/EAN 839128006270

MOTU 28×32 USB3 interface with mix, FX for Mac/Win
