MOTU 32×34 TB4/USB4 interface with mix, FX, AVB

The MOTU 10pre is a 26×28 Thunderbolt 4 / USB4 audio interface built around ten transparent mic/line/instrument preamps — eight on the rear panel for permanent wiring and two on the front for on-the-spot connections. ESS Sabre32 conversion delivers 125 dB of dynamic range at up to 24-bit/192kHz, with -129 dBu EIN, -114 dB THD+N and round-trip latency as low as 1.8 ms across 54 simultaneous channels.

Each combo XLR/TRS input offers +74 dB of gain, a -20 dB pad, 48V phantom power, phase invert and full remote control, with dedicated send/return inserts on channels 1-2 for outboard processing. Eight DC-coupled TRS line outputs, two banks of 8-channel optical I/O and word clock provide monitoring, digital expansion and sync, and an optical-expander mode adds further inputs and outputs from a single front-panel preset.

A 32-bit floating-point DSP engine runs a 64-channel, 32-bus mixer with reverb, EQ, gate and compression, controllable from CueMix Pro over USB, Wi-Fi or the network. Dual Gigabit AVB ports daisy-chain up to eight 10pre, 848 or 16A units for hundreds of networked channels, while a 3.9-inch RGB TFT display, two headphone outputs, loopback and A/B/C monitoring with talkback complete the 1U chassis.

Visit Support Site

SKU MOT-16A

MOTU 32×34 TB4/USB4 interface with mix, FX, AVB

RRP $2999.00

26×28 Thunderbolt 4 / USB4 interface, 54 simultaneous channels
10x combo XLR/TRS mic/line/hi-Z preamps, +74 dB gain
8 rear-panel + 2 front-panel mic inputs for on-the-fly tracking
ESS Sabre32 DAC, 125 dB dynamic range, up to 192 kHz

Vendor Item No. 9321
UPC/EAN 839128006287
